Heavy-Duty Concrete Deck for an Underground Mining Truck

3D model render of a heavy-duty concrete deck with steel girders and an underground mining truck in position
  • Project: Heavy-duty concrete deck, 10 m × 4.5 m
  • Design vehicle: Fully loaded 113 t underground mining truck, axle loads up to 62 t
  • Scope: Load cases, steel girder and reinforced concrete deck design
  • Standards: AS 4100, AS 3600 and AS/NZS 1170

The brief

This project involved the structural design of a 10 m × 4.5 m heavy-duty concrete deck for a fully loaded underground mining truck, with axle loads of up to 62 tonnes. Few structures see wheel loads this concentrated, and the deck had to carry them safely, day after day, under demanding mine site conditions.

Our engineering approach

Using a 3D model of the deck with the design vehicle in position, we developed the critical design load cases from the manufacturer’s axle data and designed the steel girders and the reinforced concrete deck.

Our checks covered bending, shear, deflection and support reactions under the heavy wheel loads, including dynamic and off-centre loading, lateral restraint of the girders and uplift at the supports. The design was carried out to AS 4100, AS 3600 and AS/NZS 1170, and the deck reinforcement was selected to safely resist all of these forces, with bar sizes and spacings chosen for the heaviest wheel loads.

Outcome

The result is a robust, buildable deck backed by clear calculations and drawings, giving the client confidence in its long-term performance under demanding mine site conditions.
